The 20-head combination weigher has two weighing modes. One is the mixing mode. The weighing range of the mixing mode is 20-2000g. According to the material, the maximum weighing speed can reach 65 bags/minute. Another weighing mode is a high-speed mode for a single material, the weighing range is 10-1000g, and the maximum weighing speed can reach 120 bags/min. Both models can be connected to the twin packaging machine, which can be used for weighing or packaging, forming a simple weighing and packaging system.
Scope of Application
Standard 20 heads multihead weigher is suitable for weighing a single material with high-speed or various mixing products, such as oatmeal, mixing nuts etc.
Technical Specifications
| Model | JW-A20 | JW-A20 |
| Identify Code | A20-2-1(O type) | A20-2-1(8 type) |
| Weighing Range | 10-1000g | 10-1000g |
| Accuracy | X(0.5) | X(0.5) |
| Max Speed | 2*65P/M (Twin Packing Machine Mode) | 2*65P/M (Twin Packing Machine Mode) |
| Hopper Volume | 1.6L/2.5L | 1.6L/2.5L |
| Control Panel | 10.4” Touch Screen | 10.4” Touch Screen |
| Options | Dimple Plate/ Timing Hopper/ Printer/ Reject Device | Dimple Plate/ Timing Hopper/ Printer/ Reject Device |
| Driving System | Step Motor | Step Motor |
| Power Requirement | 220V/2000W/ 50/60Hz /16A | 220V/2000W/ 50/60Hz /16A |
| Packing Dimension(mm) | 1920(L)*1650(W)*1620(H) | 1880(L)*1600(W)*1240(H) |
| Gross Weight | 850kg | 850kg |
